| Pixel Pitch (mm) |
1.9 |
2.53 |
| LED Type |
SMD1515 |
SMD1515 |
| Module Size(WxH) (mm) |
304×342 |
304×342 |
| Pixel Per Module (Dots) |
160×180 |
120×135 |
| Module Weight (Kg) |
1.3 |
1.3 |
| Size(WxHxT) |
608x342x76mm |
608x342x76mm |
| Pixels (dots) |
320×180 |
240×135 |
| Material |
Aluminum |
Aluminum |
| Weight (Kg) |
6.3 |
6.3 |
| Brightness (nit) |
900 |
900 |
| Processing depth (bit) |
14 |
14 |
| Display refresh rate (Hz) |
2520 |
3000 |
| Color Temperature (K) |
3200~9300 |
3200~9300 |
| Viewing angle(H) (deg) |
160 |
160 |
| Viewing angle(V) (deg) |
140 |
140 |
| Drive type |
1/30 Scan |
1/27 Scan |
| AC Operating Voltage (V) |
100~240 |
100~240 |
| AC Input Frequency (Hz) |
50/ 60 |
50/ 60 |
| Power Consumption (Max./Avg.) (W/m²) |
500/167 |
500/167 |
| Storage Temperature (℃) |
﹣40~﹢60 |
﹣40~﹢60 |
| Operating Temperature (℃) |
﹣10~﹢40 |
﹣10~﹢40 |
| Storage Humidity (RH) |
10﹪~90﹪ |
10﹪~90﹪ |
| Operating Humidity (RH) |
10﹪~90﹪ |
10﹪~85﹪ |
| IP Rating (Front/Rear) |
IP30/IP30 |
IP30/IP30 |
| Module Maintenance |
Front |
Front |
| PSU & Others Maintenance |
Front |
Front |
| Panel Installation Type |
Front Installation |
Front Installation |
| Maximum number of panel for Lifting (PCS) |
/ |
/ |
