LEDMan Outdoor Fixed LED Display L Series

Brand:

  • LEDman
Availability: In Stock
SKU: L-Series Categories: , ,

The latest in the outdoor range from Ledman, the L Series is suited to all but the largest outdoor displays. With the exception of the L2, all panels can be installed and maintained from both front and rear.
L Series enclosures are IP rated with IP65 to the front for maximum protection and IP54 to the rear. They are sealed against insects and provide maintenance free operation with no fans required.

  • SMD Technology
  • Pixel Pitch 2.8mm to 6.3mm
  • Front & Rear Service
  • High Brightness
  • IP65/IP54 (front/rear)



SPECIFICATIONS



Model

L2

L3.1

L3

L4

L5

L6

Pixel Pitch (mm) 2.8 3.125 3.9 4.8 5.95 6.25
Module Size(mm) 250*250
Panel Size (mm) 1000*500*91 750*750*94 1000*500*91

1000*750*91

1000*500*91

1000*750*91

1000*500*95

1000*750*95

1000*500*91

1000*750*91

Pixel (dot) 352*176 240*240 256*128

256*192

208*104

208*156

168*84

168*126

160*80

160*120

Material Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum
Weight (kg) 36 41 34 35 35 35
Brightness(nit) 4000 4500 5500 5500 6500 6500
Gray scale (bit) 14-16 14-16 14-16 14-16 14-16
Refresh rate(Hz) 3840 3840 3840 3840 2000
Power Max./Avg. (W/㎡) 650/216 665/222 750/250 720/240 750/250 750/250
IP Rating(Front/Rear) IP65/IP54 IP65/IP54 IP65/IP54 IP65/IP54 IP65/IP54 IP65/IP54
Installation/Maintenance Rear Front & Rear Front & Rear Front & Rear Front & Rear Front & Rear
